Custom PCB Socket Plastic 1P Connector Multipole Female Receptacle

1.Push pull self-latching system
2.Full EMC shielding
3.Solder or PCB print contacts
4.Multi-pole / 1P: 2~14 contacts, 2P: 3~16 contacts.
5.High density installation to save space
6.Plastic housing,2 leaf-springs locking, groove to avoid rotation
7.Tinted back nut of plugs and round nut of sockets to avoid mismating
8.Protection class(mated): IP50 or IP65
9.Product Certificate:UL
Availability:
Quantity:
  • SBG.1P308.APVG
  • REUNION

REUNION CONNECTORS-FOCUS ON CONNECTOR CUSTOMIZATION SOLUTIONS



Custom PCB Socket Plastic 1P Connector Multipole Female Receptacle


Push and pull self-locking system is known for simple and quick mating. It can effectively resist vibration and shock, and can prevent the disconnection caused by pulling the cable. It is absolutely safe and reliable to use, which facilitates the insertion and removal in a very limited space.


1- Fast  and security of the Push-Pull self-latching system
2- Keying system (standard Key "G", or keys A/ B options ) for connector alignment
3- A half of stepped-type with both a male and female ferrule cores in polarity status
4- Multi-core type with 1P2 to 14, and 2P3 to 16 cores
5- Watertight connection (IP65/ IP50)
6- Solder and PCB-printed type connector pins(straight or elbow 90-degree )
7- Color coded key options for system security , keys ensuring ease of blind mating.
8- 360 degree screening for full EMC shielding
9- Plastic housing,watertight index IP50, IP65, doouble spring lock with groove to prevent rotation
10- High-density installation to save space


Product Specification:


PCB socket


1P SERIES:


PAG Straight Plug, IP50:

straight plug


PFG Straight Plug, IP65:

Plastic coupler


SKG Fixed Socket, Panel, IP50:

Medical connector

SKG Fixed Socket,PCB,IP50:

medical adapter


SKG Fixed Socket,PCB,IP50:

PCB mount female connector


SNG Fixed Socket, Panel, IP65:

IP65 waterproof connector


SBG Fixed Socket, PCB, IP50:

female


Poduct Application:


plastic connectors


Our Company:


Since 2011, we have successfully shipped lots of products and earned good reputation from our customers all over the world.

Our main products is electrical connector. Meanwhile, we could provide all kinds of connectors as low voltage connectors, plastic connectors, miniature connectors, inserts series B K S F P M X N RJ45, high pressure connectors, high voltage connectors, cable assemblies, accessories, other/special. And OEM, ODM projects are welcome, and we have a delicated engineering team , quality control , production and merchandiser team to give you fully support .

cable assembly


Exhibition:

Medical power connector


Certificate:

medical connector cable assemnly
